Basic Data |
level |
Medium and large SUV |
energytype |
Extender |
time to market |
2022.07 |
electric motor |
Extended range 272 horsepower |
Pure electric cruising range (km) Ministry of Industry and Infbrmation Technology |
195 |
Pure electric cruising range (km)WLTC |
195 |
Pure electric cruising range (km) CLTC |
230 |
Comprehensive cruising range (km) Ministry of Industry and Information Technology |
1,220 |
Charging time (hours) |
Fast charge for 0.5 hours Slow charge for 5 hours |
Quick charge capacity (%) |
30-80 |
Maximum power (kW) |
200(272Ps) |
Maximum torque (N m) |
360 |
gearbox |
Electric vehicle single speed gearbox |
Leiygfli x width x height (皿舟 |
5020x1945x1775 |
Body structure |
5-door 6-seat SUV |
Maximum speed(km/h) |
190 |
Official 100km acceleration time (s) |
7.8 |
WETC comprehensive fiiel consumption (17100蜘) |
1.05 |
Power consumption per 100 kilometers (kWh/]00km) |
twenty three |
Electric energy equivalent fuel consumption (L/lOOkm) |
1.05 |
Minimum state of charge fuel consumption (L/100km) |
6.85 |
Vehicle Warranty Period |
4 years or 100,000 kilometers |
Estimated total cost of maintenance for 60,000 kilometers |
- |
body |
length (mm) |
5,020 |
width (mm) |
1,945 |
height (mm) |
1,775 |
Wheelbase (mm) |
2,820 |
Front track(mm) |
1,635 |
Rear track(mm) |
1,650 |
Body structure |
SUV |
Number of doors (a) |
5 |
Door opening method |
side hinged door |
Number of seats (pieces) |
6 |
curb weight(kg) |
2,340 |
Full load mass(kg) |
2,790 |
Fuel tank capacity (L) |
60.0 |
Luggage compartment volume (L). |
176-688 |
engine |
engine model |
H15RT |
Displacement (mL) |
1,499 |
Displacement (L) |
1.5 |
Intake fbrm |
turbocharged |
Cylinder arrangenieiit |
L |
Number of cylinders (pieces) |
4 |
Number of valves per cylinder (pieces) |
4 |
compression ratio |
- |
Air Supply |
DOHC |
Maximum horsepower (Ps) |
125 |
Maximum power (kW) |
92 |
Maximum power speed(rpni) |
- |
Maximum torque (N m) |
205 |
Maximum torque speed(rpm) |
- |
Engine Specific Technology |
- |
fiiel fbrm |
Extender |
fixel label |
95# |
Fuel supply method |
Multi-point EFI |
Cylinder head material |
aluminum |
Cylinder material |
iron |
Environmental standards |
Country VI b |
electric motor |
Motor descript妬n |
Extended range 272 horsepower |
motor type |
Permanent magnet/synchronous |
Total motor power (kW) |
200 |
Motor total horsepower (Ps) |
272 |
Motor total torque (N m) |
360 |
Maximum power of the firont motor (kW) |
- |
Front motor maximum torque .(Nm). |
- |
Maximum power of rear motor ,(kW). |
200 |
Maximum torque of rear motor .(Nm). |
360 |
Number of drive motors |
single motor |
Motor layout |
rear |
Charging batteries |
Battery Type |
Ternary lithium battery |
Battery brand |
CATL |
Battery Pack Warranty |
8 years or 160,000 kilometers |
Battery capacity (kWh) |
40 |
Battery energy density (Wh/kg) |
- |
Charging batteries |
Fast charge for 0.5 hours Slow charge for 5 hours • Fast charging port |
Fast charging interface location |
left fuel tank |
Slow charging interface location |
left fuel tank |
Battery Temperature |
. low temperature heating |
Management System |
・ liquid cooling |
one pedal mode |
- |
VTOL mobile power station fimction |
• Standard |
Maximum external discharge power (kW) |
3.5 |
Charging 一 pile |
Optional 1 charging pile o power 7kW |
gearbox |
Gearbox Description |
Electric vehicle single speed gearbox |
Gears |
1 |
gearbox type |
fixed gear ratio gearbox |
Chassis/Steering |
drive mode |
rear drive |
4WD type |
- |
Front suspension |
McPherson independent suspension |
rear suspension |
Multi-link independent suspension |
steering type |
electric assist |
Body structure |
load-bearing |
Wheels/brakes |
Front Brake Type |
Ventilated Disc |
rear brake type |
Ventilated Disc |
Parking Brake Type |
electronic parking |
|
Front tire size |
255/50 R20 |
Rear tire size |
255/50 R20 |
Spare tire specifications |
- |
Spare tire placement |
- |
active safety • Standard ° i |
Optional - none |
ABS anti-lock brake |
Standard |
Braking force distribution (EBD/CBC. etc.) |
Standard |
Brake Assist (EBA/BA etc.) |
Standard |
Traction Control (TCS/ASR etc,). |
Standard |
Body stabilization system (ESP/DSC. etc.) |
Standard |
|
lane departure warning |
|
forward collision warning |
Active Sa企ty Warning System |
Reversing vehicle side warning |
|
DOW open door warning |
active braking |
Standard |
Parallel Assist |
Standard |
Lane Keeping Assist |
Standard |
lane centering |
Standard |
Fatigue Driving Tips |
Standard |
Active DMS Fatigue Detection |
Standard |
In-vehicle vital sign detection |
- |
Road Traffic Sign Recognition |
• Standard |
Signal light recognition |
- |
night vision system |
- |
passive safety ・ Standard 。 |
Optional - none |
front airbag |
・ driver's seat |
• co-pilot |
side airbag |
• front row |
• back row |
side curtain airbags |
, Standard |
fixmt knee airbag |
- |
central airbag |
- |
Seat belt not fhstened reminder |
• Standard |
tire pressure monitoring system |
• tire pressure display |
Child seat interface (ISOFIX) |
• Standard |
passive pedestrian protection |
- |
safety tire |
- |
Assist/Control Configuration |
・ Standard 。 Optional - none |
parking radar |
. forward |
• rear |
Reminder of the vehicle ahead |
- |
Driving Assistance Video |
• Reverse image |
• 360° panoramic image |
|
• cruise control |
cruise system |
・ adaptive cruise |
|
• Full speed adaptive cruise |
Automatic Lane Change Assist |
- |
Ramp automatic exit (entry) |
- |
Assisted driving level |
• L2 level |
automatic parking |
・ Standard |
Tracking and reversing |
- |
memory parking |
- |
Automatic parking (AUTOHOLD) |
• Standard |
Hill Assist (HAC) |
• Standard |
Hill descent (HDC) |
, Standard icon |
Engine Start-Stop Technology |
- |
Variable Suspension Adjustment |
- |
air suspension |
- |
Electromagnetic induction suspension |
- |
Variable Steering Ratio System |
- |
Front axle limited slip mode |
- |
Rear axle limited slip mode |
- |
Center differential lock fimction |
- |
Low-speed fbur-wheel drive |
- |
Integral Active Steering |
- |
|
• sports |
driving mode selection |
• ECO |
• personalise |
|
. standard comfort |
Brake Energy Recovery System |
• Standard |
Low-speed driving warning • Standard sound external conHguration • Standard 。Optional - none |
skylight type |
• Openable panoramic sunroof |
light-sensitive canopy |
- |
roof rack |
- |
sporty appearance kit |
- |
electric spoiler |
- |
Active closed air intake grille |
- |
Aluminum alloy wheels |
• Standard |
side pedal |
- |
Frameless design doors |
- |
hidden door handle |
・ Standard |
tow hook |
- |
internal configuration • Standard 。Optional - none |
steering wheel material |
• Genuine Leather |
steering wheel adjustment |
up and down + front and • back |
Electric steering wheel adjustment |
- |
steering wheel fimction |
• multifunction control |
trip computer screen |
• color |
LCD instrument style |
・ Full LCD |
LCD Meter Dimensions (inches) |
-10.25 |
Comfort/Anti-Theft Configuration • Standard 。 Optional - |
Electric suction door |
- |
electric tailgate |
• Standard icon |
Inductive tailgate |
- |
Electric tailgate position memory |
• Standard |
Engine electronic anti-theft |
• Standard |
Central locking in the car |
• Standard |
|
, smart remote key |
Key fob type |
• mobile phone bluetooth key |
• wearable key |
|
• NFC/RFID key |
keyless entry |
• whole car icon |
keyless start |
• Standard icon |
remote start |
• Standard |
remote control vehicle |
- |
vehicle call fimction |
- |
Head-Up Display (HUD) |
• Standard |
Built-in driving recorder |
• Standard |
Active Noise Cancellation |
• Standard |
mobile phone wireless charging |
• Standard icon |
Mobile phone wireless charging maximum power (W) |
40 |
110V/220V/230V power socket |
• Standard |
Luggage compartment 12V power interface |
• Standard |
seat configuration ・ Standard |
。Optional - none |
seat material |
genuine leather + imitation leather |
sporty seat |
- |
seat layout |
-2+2+2 |
Second row individual seats |
・ Standard |
third row seats |
. 2 seats |
|
・ driver's seat |
Electric Seat Adjustment |
• co-pilot |
|
• second row |
|
• move back and forth |
Overall adjustment of the driver's seat |
backrest angle |
|
height adjustment |
Partial adjustment of the |
headrest |
driver's seat |
waist |
|
move back and forth |
Overall adjustment of passenger seat |
height adjustment backrest angle |
Partial adjustment of passenger |
headrest |
seat |
waist |
Overall adjustment of the |
move back and forth |
second row of seats |
Backrest angle adjustment |
Second row seat partial |
leg rest |
a4justment |
waist |
|
heating |
什 ont seat fimction |
ventilation |
Memory (main driver) |
|
massage |
|
heating |
Second row seat fimctions |
ventilation |
|
massage |
Third row seat fimction |
|
boss key |
Standard icon |
fixmt/rear armrest |
front row |
back row |
rear cud holder |
Standard |
Heated/cooled cup holder |
- |
Rear seat down ratio |
• 50:50 |
Rear seat electric down |
- |
Second row of small table boards |
- |
Smart Internet • Standard |
。Optional - none |
Central control screen size (inches) |
• 15.6 |
Touch screen vibration feedback |
- |
screen layout |
Traditional dual-screen • layout |
GPS navigation system |
• Standard |
AR real-world navigation |
- |
Navigation traffic infbrmation display |
• Standard |
roadside assistance service |
• Standard icon |
Bluetooth/Car Phone |
• Standard |
Mobile [ntemet Mapping |
.Original machine |
Internet of Vehicles |
• Standard |
4G/5G network |
• 4G |
OTA upgrade |
• Standard |
fhce recognition |
• Standard |
Fingerprint recognition |
- |
voiceprint recognition |
- |
emotion recognition |
- |
Vbice recognition control system |
• Standard |
Voice free wake-up function |
• Standard |
|
-main driver |
Voice sub-area wake-up recognition function |
• co-pilot |
• second row |
Continuous Speech Recognition |
• Standard |
see can say |
• Standard |
voice assistant wake word |
Xiaoyi Xiaoyi |
gesture control |
- |
Wi-Fi hotspot |
- |
Media entertainment • Standard ° Optional - none |
Multi-finger flying screen control |
- |
app Store |
・ Standard |
multimedia interface |
. USB/Type-C |
Number of USB/Type-C ports |
. 4 front row |
• 2 back row |
USB/Type-C maximum |
Front row 66W |
charging power |
Rear row 66W |
Car TV |
- |
rear LCD screen |
- |
simulated sound waves |
• Standard |
Soothe (Relax) Mode |
・ Standard |
Karaoke function |
・ Standard |
audio brand |
- |
Number of speakers (units) |
• 19 |
rear multimedia controls |
- |
lighting configuration • Standard 。Optional - none |
Low beam lights |
・led |
High beam |
, led |
daytime running lights |
• Standard |
Adaptive far and near light |
• Standard |
automatic headlights |
• Standard |
turn signal lamp |
- |
Front fog lights |
- |
Penetrating headlights |
- |
through tail lights |
• Standard |
Headlight Adaptive Steering (AFS). |
- |
headlight height adjustment |
・ Standard |
headlight cleaning fimction |
- |
interior ambient light |
・ 128 colors |
Active Ambient Mood Lighting |
・ Standard |
Lighting Features |
- |
Delayed headlight o任 |
• Standard |
Headlight rain and fbg mode |
- |
glass/mirror • Standard 。 |
Optional - none |
electric windows |
• front row |
• back row |
One-button window lift |
• whole car |
Window anti-pinch fiinction |
• Standard |
|
• electric adjustment icon |
|
• heating |
|
• electric folding |
Exterior mirror function |
, memory |
|
Automatic downturn when reversing |
Automatic folding when • locking the car |
Interior rearview mirror |
• Automatic anti-glare |
fimction |
|
|
Main driving position + |
vanity mirror |
lighting |
|
• Passenger seat + lighting |
rear privacy glass |
• Standard |
interior sunshade |
- |
Rain Sensing Wipers |
• Standard |
rear wiper |
・ Standard |
rear window open |
- |
Multi-layer soundproof glass |
• whole car |
Front windshield electric |
|
heating |
|
heated water nozzle |
- |
air conditioner/refrigerator • |
Standard 。Optional - none |
Air Conditioning Control |
|
Mode |
• automatic |
Rear independent air |
|
conditioner |
|
rear air outlet |
• Standard |
Temperature zone control |
• Dual Zone Air Conditioning |
Car air purifier |
• Standard |
In-car PM2.5 filter |
• Standard |
HEPA filter |
- |
negative ion generator |
• Standard |
car firagrance device |
, Standard icon |
car refrigerator |
- |
Intelligent configuration |
Vehicle Intelligent System |
HarmonyOS |
Vehicle Smart Chip |
Kirin 990A |
In-vehicle system memory (GB) |
6 |
In-vehicle system storage (GB) |
128 |
|
digital key |
|
vehicle monitoring |
Mobile Ajpp remote control |
remote control |
charge management |
|
service appointment |
|
Smart car search assistant |
heat pump management system |
- |
Number of cameras outside the car (units) |
• 6 |
Number of cameras in the car (units) |
-2 |
Ultrasonic radar quantity (unit) |
-12 |
Number of millimeter wave radars (units) |
・3 |
Sub-meter high-precision positioning system |
- |
HD map |
- |
Sentry (clairvoyance) mode |
- |
V2X communication |
|
