BASIC DATA | |||
Make | Series Automobile | ||
Model | Extended Range Max RWD Advanced Intelligent Driving | Extended Range Max RS 4WD Advanced Intelligent Driving | Pure Electric Max RWD Advanced Intelligent Driving |
Car Type | Mid-size SUV | ||
Pure electric cruising range (km) CLTC | 195km | 175km | 602km |
Max Power | 200(272Ps) | 365(496Ps) | 200(272Ps) |
Max Torque | 310N.m | ||
Gearbox | Electric vehicle single-speed gearbox | ||
Overalls | 4785x1930x1625 | ||
Body Structure | 5-door 5-seater SUV | ||
Max Speed | 200km/h | 210km/h | 200km/h |
CAR BODY | |||
Wheelbase | 2880mm | ||
Seats | 5 | ||
Luggage compartment volume (L) | 369-776 | 449-856 | |
Curb Weight | 2220kg | 2335kg | 2235kg |
Full Load Weight | 2595kg | 2710kg | 2610kg |
Engine | |||
Engine Model | H15RT | ||
Displacement (mL) | 1499 | ||
Air intake form | Turbocharger | ||
Engine layout | Sideways | ||
ELECTRIC MOTOR | |||
Motor Description | Extended range 272 hp | Extended range 496 hp | Pure electric 272 hp |
Motor Type | Permanent magnet/synchronous | AC/asynchronous at the front and permanent magnet/synchronous at the back | Permanent magnet/synchronous |
Number of Drive Motors | Single Motor | Dual motors | Single Motor |
Motor Layout | Rear | 4WD | Rear |
CHASSIS | |||
Drive | RR | Front + Rear | RR |
Front Suspension | Double wishbone independent suspension | ||
Rear Suspension | Multi-link independent suspension | ||
CHARGING BATTERIES | |||
Battery Type | Ternary lithium battery | ||
Battery Brand | CALL | ||
Charging batteries | Fast charge 0.5 hours Slow charge 5 hours | Fast charge 0.5 hours Slow charge 10.5 hours | |
Battery capacity (kWh) | 42 | 83 | |
WHEELS & BRAKE | |||
Front Brake | Ventilated Disc | ||
Rear Brake | Ventilated Disc | ||
Parking Brake | Electronic parking | ||
Front Tyres | 255/50 R19 | 255/45 R20 | 255/50 R19 |
Rear Tyres | 255/50 R19 | 255/45 R20 | 255/50 R19 |
