Basic Data | |
manufacturers | ZEEKR |
level | Medium and large MPV |
energyjype | pure electric |
time to market | 2022.11 |
electric motor | Pure electric 544 horsepower |
Pure electric cruising range (km) Ministry of Industry and Information Technology | 702 |
Pure electric cruising range (km) CLTC | 702 |
Charging time (hours) | Fast charge 0.47 hours |
Quick charge capacity (%) | 10-80 |
Maximum power (kW) | 400(544Ps) |
Maximum torque (N・m) | 686 |
gearbox | Electric vehicle single speed gearbox |
Length x width x height .(mm). | 5209x2024x1848 |
Body structure | 5-door 6-seater MPV |
Maximum speed(km/h) | 190 |
Official 100km acceleration time (s) | 4.5 |
Power consumption per 100 kilometers fkWh/100km) | 18.3 |
Electric energy equivalent fuel consumption | 2.07 |
(L/100km) | |
Vehicle Warranty Period | 6 years or 150,000 kilometers |
body | |
length (mm) | 5,209 |
width (mm) | 2,024 |
height (mm) | 1,848 |
Wheelbase (mm) | 3,205 |
Front track(mm) | 1,701 |
Rear track(mm) | 1,713 |
Body structure | MPV |
Number of doors (a) | 5 |
Door opening method | sliding door |
Number of seats (pieces) | 6 |
curb weight(kg) | 2,830 |
Full load mass(kg) | 3,320 |
Lug gage compartment volume (L) | 376-2979 |
Drag Coefficient (Cd) | 0.27 |
electric motor | |
Motor description | Pure electric 544 horsepower |
motor type | Permanent magnet/synchronous |
Total motor power (kWl | 400 |
Motor total horsepower .(Es). | 544 |
Motor total torque (N m) | 686 |
Maximum power of the front motor (kW) | 200 |
Front motor maximum torque (N m) | 343 |
Maximum power of rear motor (kW) | 200 |
Maximum torque of rear motor (N m) | 343 |
Number of drive motors | dual motor |
Motor layout | front + rear |
Charging batteries | |
Battery Type | Ternary lithium battery |
Battery brand | CATL |
Battery Pack Warranty | Unlimited years/mileage for the first owner |
Battery capacity (kWh) | 116 |
Battery energy density .(WhZkg). | 177.0 |
Charging batteries | Fast charge 0.47 hours |
• Fast charging port | |
Fast charging interface location | left fuel tank |
Slow charging interface location | left fender |
Battery Temperature Management System | low temperature . heating |
. liquid cooling | |
one pedal mode | • Standard |
Brand self-operated charging station | • Standard |
VTOL mobile power station function | • Standard |
Maximum external discharge power (kW) | 3.3 |
Charging pile | Optional 1 charging pile 0 power 11 kW |
gearbox | |
Gearbox Description | Electric vehicle single speed gearbox |
Gears | 1 |
gearbox type | fixed gear ratio gearbox |
Chassis/Steering | |
drive mode | Dual motor four-wheel drive |
4WD type | Electric four-wheel drive |
Front suspension | Double wishbone independent suspension |
rear suspension | Multi-link independent suspension |
steering type | electric assist |
Body structure | load-bearing |
Wheels/brakes | |
Front Brake Type | Ventilated Disc |
rear brake type | Ventilated Disc |
Parking Brake Type | electronic parking |
Front tire size | 255/50 R19 |
Rear tire size | 255/50 R19 |
Spare tire specifications | - |
active safety | |
ABS anti-lock brake | Standard |
Braking force distribution (EBD/CBC etc.) | Standard |
Brake Assist (EBA/BA etc.) | Standard |
Traction Control (TCS/ASR etc). | Standard |
Body stabilization system (ESP/DSC. etc.) | Standard |
lane departure warning | |
Active Safety Warning System | forward collision warning |
Reversing vehicle side warning | |
DOW open door warning | |
active braking | Standard |
Parallel Assist | Standard |
Lane Keeping Assist | Standard |
lane centering | Standard |
Fatigue Driving Tips | Standard |
Active DMS Fatigue Detection | Standard |
In-vehicle vital sign detection | - |
Road Traffic Sign Recognition | 。Optional |
Signal light recognition | 。Optional |
night vision system | - |
passive safety | |
front airbag | • driver's seat |
• co-pilot | |
side airbag | • front row |
side curtain airbags | • Standard |
front knee airbag | - |
central airbag | - |
Seat belt not fastened reminder | • Standard |
tire pressure monitoring system | • tire pressure display |
Child seat interface (ISOFIX) | • Standard |
passive pedestrian protection | - |
safety tire | 。Optional |
Assist/Control Configuration | |
parking radar | • forward |
• rear | |
Reminder of the vehicle ahead | - |
• Reverse image | |
Driving Assistance Vide。 | • 360° panoramic image |
• transparent image | |
• cruise control | |
cruise system | • adaptive cruise |
Full speed adaptive • cruise | |
Automatic Lane Change Assist | 。Optional |
Ramp automatic exit (entry) | 。Optional |
Assisted driving level | • L2 level |
automatic parking | • Standard |
Tracking and reversing | - |
memory parking | 。Optional |
Automatic parking (AUTOHOLD) | • Standard |
Hill Assist (HAC) | • Standard |
Hill descent (HDC) | • Standard icon |
Variable Suspension Adjustment | Soft and hard + high and low |
air suspension | • Standard |
Electromagnetic induction suspension | • Standard |
Variable Steering Ratio System | - |
Front axle limited slip mode | - |
Rear axle limited slip mode | - |
Center differential lock function | - |
Integral Active Steering | - |
• sports | |
• ECO | |
driving mode selection | • the snow |
• personalise | |
• standard comfort | |
Brake Energy Recovery System | • Standard |
Low-speed driving warning sound | • Standard |
external configuration | |
skylight type | Segmented non- • openable panoramic sunroof |
light-sensitive canopy | - |
roof rack | - |
sporty appearance kit | - |
electric spoiler | - |
Active closed air intake | • Standard |
grille | |
sliding door | Electric opening and • closing on both sides |
Aluminum alloy wheels | • Standard |
side pedal | - |
Frameless design doors | - |
hidden door handle | - |
tow hook | - |
internal configuration | |
steering wheel material | • Genuine Leather |
steering wheel | up and down + front |
adjustment | and back |
Electric steering wheel | |
adjustment | |
steering wheel function | • multifunction control • heating |
trip computer screen | • color |
LCD instrument style | • Full LCD |
Comfort/Anti-Theft Configuration | |
Electric suction door | • Standard |
electric tailgate | • Standard |
Inductive tailgate | - |
Electric tailgate position | • Standard |
memory | |
Central locking in the car | • Standard |
• smart remote key | |
• NFC/RFID key | |
Key fob type | • UWB digital key |
mobile phone bluetooth key | |
keyless entry | • whole car |
keyless start | • Standard |
remote start | • Standard |
remote control vehicle | • Standard |
vehicle call function | - |
Head-Up Display (HUD) | - |
Built-in driving recorder | • Standard |
Active Noise Cancellation | - |
mobile phone wireless charging | • Standard |
Mobile phone wireless charging maximum power (W) | 15 |
110V/220V/230V power | |
socket | |
Lug gage compartment 12V power interface | • Standard |
seat configuration | |
seat material | Genuine Leather |
seat leather style | Nappa leather |
sporty seat | |
seat layout | 2+2+2 |
Second row individual seats | Standard |
third row seats | 2 seats |
driver's seat | |
Electric Seat Adjustment | co-pilot |
second row | |
move back and forth | |
Overall adjustment of the driver's seat | backrest angle |
height adjustment | |
Partial adjustment of the | headrest |
driver's seat | waist |
move back and forth | |
Overall adjustment of passenger seat | height adjustment backrest angle |
Partial adjustment of passenger seat | headrest |
Overall adjustment of the second row of seats | move back and forth |
Backrest angle adjustment | |
Second row seat partial | leg rest |
front seat function | heating |
ventilation | |
Memory (main driver) | |
Massage (driver) | |
heating | |
Second row seat | memory |
functions | ventilation |
massage | |
Third row seat function | |
boss key | Standard icon |
front/rear armrest | front row |
back row | |
rear cup holder | Standard |
Heated/cooled cup holder | - |
Rear seat down ratio | • 50:50 |
Rear seat electric down | - |
Second row of small table boards | • Standard |
Smart Internet | |
Central control screen size (inches) | • 15.4 |
Touch screen vibration feedback | • Standard |
screen layout | Traditional dual-screen • layout |
GPS navigation system | • Standard |
AR real-world navigation | |
Navigation traffic information display | • Standard |
roadside assistance | • Standard icon |
service | |
Bluetooth/Car Phone | • Standard |
Mobile Internet Mapping | • Original machine |
Internet of Vehicles | • Standard |
4G/5G network | • 5G |
OTA upgrade | • Standard |
face recognition | • Standard |
Fingerprint recognition | — |
voiceprint recognition | - |
emotion recognition | - |
Voice recognition control | • Standard |
system | |
Voice free wake-up function | • Standard |
• main driver | |
Voice sub-area wake-up | • co-pilot |
recognition function | • second row |
• third row | |
Continuous Speech Recognition | • Standard |
see can say | • Standard |
voice assistant wake word | Hi, EVA |
gesture control | - |
Wi-Fi hotspot | • Standard |
Media entertainment | |
Multi-finger flying screen control | - |
app Store | • Standard |
multimedia interface | • hdmi |
• USB/Type-C | |
Number of USB/Type-C | • 2 front row |
ports | • 5 back row |
USB/Type-C maximum | Front row 18W |
charging power | Rear row 60W |
Car TV | - |
rear LCD screen | • Standard |
simulated sound waves | - |
Soothe (Relax) Mode | • Standard |
audio brand | • yamaha |
Number of speakers (units) | • 20 |
rear multimedia controls | • Standard |
lighting configuration | |
Low beam lights | • led |
High beam | • led |
daytime running lights | • Standard |
Adaptive far and near light | • Standard |
automatic headlights | • Standard |
turn signal lamp | - |
Front fog lights | - |
Penetrating headlights | - |
through tail lights | • Standard |
Headlight Adaptive Steering (AFS) | • Standard |
headlight height adjustment | • Standard |
headlight cleaning function | - |
interior ambient light | • multicolor |
Active Ambient Mood Lighting | - |
Lighting Features | • Matrix |
Delayed headlight off | • Standard |
Headlight rain and fog mode | - |
glass/mirror | |
electric windows | • front row |
• back row | |
One-button window lift: | • whole car |
Window anti-pinch function | • Standard |
electric • icon adjustment | |
• heating | |
. electric folding | |
Exterior mirror function | • memory |
Automatic downturn . when reversing | |
Automatic folding when • 、一‘ locking the car | |
• Automatic anti-glare | |
Interior rearview mirror function | • Automatic anti-glare |
vanity mirror | Main driving position + lighting |
Passenger seat + lighting | |
rear privacy glass | • Standard |
interior sunshade | - |
Rain Sensing Wipers | • Standard |
rear wiper | • Standard |
Multi-layer soundproof glass | • whole car |
Front windshield electric heating | - |
heated water nozzle | - |
air conditioner/refrigerator | |
Air Conditioning Control Mode | • automatic |
Rear independent air conditioner | • Standard |
rear air outlet | • Standard |
Temperature zone control | Three-zone air • conditioning |
Car air purifier | - |
In-car PM2.5 filter | • Standard |
HEPA filter | - |
negative ion generator | - |
car fragrance device | • Standard icon |
car refrigerator | - |
Intelligent configuration | |
Assisted driving operating system | • ZEEKR AD |
Assisted driving chip | • Mobileye EyeQ5H x 2 |
Vehicle Intelligent System | • ZEEKR OS |
Vehicle Smart Chip | Qualcomm Snapdragon , 8155 |
. digital key | |
• vehicle monitoring | |
Mobile App remote control | • remote control |
• charge management | |
• service appointment | |
heat pump management | • Standard |
system | |
Forward maximum | • 250 |
detection distance (m) | |
Number of cameras | • 13 |
outside the car (units) | |
Number of cameras in the | • 2 |
car (units) | |
Ultrasonic radar quantity (unit) | • 12 |
Number of millimeter | ■ 1 |
wave radars (units) | • I |
Sub-meter high-precision positioning system | - |
HD map | • Standard |
Sentry (clairvoyance) mode | - |
V2X communication | - |
