| Basic Data | |
| manufacturers | NIO |
| level | mid-size SUV |
| energyjype | pure electric |
| time to market | 2022.06 |
| electric motor | Pure electric 435 horsepower |
| Pure electric cruising range (km) Ministry of Industry and Information Technology | 455 |
| Charging time (hours) | Fast charge 0.6 hours Slow charge 11.5 hours |
| Quick charge capacity (%) | 10-80 |
| Maximum power (kW) | 320(435Ps) |
| Maximum torque (N・m) | 610 |
| gearbox | Electric vehicle single speed gearbox |
| Length x width x height .(mm). | 4850x1965x1758 |
| Body structure | 5-door 5-seat SUV |
| Maximum speed(km/h) | 200 |
| Official 100km acceleration time (s) | 5.6 |
| Power consumption per 100 kilometers fkWh/100km) | 17.3 |
| Electric energy equivalent fuel consumption (L/100km) | 1.96 |
| Vehicle Warranty Period | 3 years or 120,000 kilometers (unlimited years/unlimited mileage for the first owner) |
| Estimated total cost of maintenance for 60,000 kilometers | 3426.0 yuan |
| body | |
| length (mm) | 4,850 |
| width (mm) | 1,965 |
| height (mm) | 1,758 |
| Wheelbase (mm) | 2,900 |
| Front track(mm) | 1,668 |
| Rear track(mm) | 1,672 |
| Body structure | SUV |
| Number of doors (a) | 5 |
| Door opening method | side hinged door |
| Number of seats (pieces) | 5 |
| curb weight(kg) | 2,290 |
| Full load mass(kg) | - |
| Lug gage compartment volume (L) | 584-1433 |
| Drag Coefficient (Cd) | 0.28 |
| electric motor | |
| Motor description | Pure electric 435 horsepower |
| motor type | Permanent magnet/synchronous |
| Total motor power (kW) | 320 |
| Motor total horsepower .(Ps). | 435 |
| Motor total torque (N m) | 610 |
| Maximum power of the front motor (kW) | 160 |
| Maximum power of rear motor (kW) | 160 |
| Number of drive motors | dual motor |
| Motor layout | front + rear |
| Charging batteries | |
| Battery Type | Lithium iron phosphate battery + ternary lithium battery |
| Battery brand | CATL |
| Battery Pack Warranty | Unlimited years/mileage for the first owner |
| Battery capacity (kWh) | 75 |
| Battery energy density .(WhZkg). | - |
| Charging batteries | Fast charge 0.6 hours Slow charge 11.5 hours |
| • Fast charging port | |
| Fast charging interface location | right fender |
| Slow charging interface location | left fender |
| Battery Temperature Management System | low temperature • heating |
| • liquid cooling | |
| one pedal mode | • Standard |
| Battery swap support | • Standard |
| Brand self-operated charging station | • Standard |
| VTOL mobile power station function | - |
| Charging pile | . Standard 1 |
| gearbox | |
| Gearbox Description | Electric vehicle single speed gearbox |
| Gears | 1 |
| gearbox type | fixed gear ratio gearbox |
| Chassis/Steering | |
| drive mode | Dual motor four-wheel drive |
| 4WD type | Electric four-wheel drive |
| Front suspension | Double wishbone independent suspension |
| rear suspension | Multi-link independent suspension |
| steering type | electric assist |
| Body structure | load-bearing |
| Wheels/brakes | |
| Front Brake Type | Ventilated Disc |
| rear brake type | Ventilated Disc |
| Parking Brake Type | electronic parking |
| Front tire size | 255/55 R19 |
| Rear tire size | 255/55 R19 |
| Spare tire specifications | - |
| Spare tire placement | - |
| active safety • Standard | 。Optional - none |
| ABS anti-lock brake | • Standard |
| Braking force distribution (EBD/CBC etc.) | • Standard |
| Brake Assist (EBA/BA etc.) | • Standard |
| Traction Control (TCS/ASR etc). | • Standard |
| Body stabilization system (ESP/DSC. etc.) | • Standard |
| • lane departure warning | |
| Active Safety Warning System | forward collision . warning |
| Reversing vehicle side o warning | |
| DOW open door • warning | |
| active braking | • Standard |
| Parallel Assist | • Standard |
| Lane Keeping Assist | 。Optional |
| lane centering | 。Optional |
| Fatigue Driving Tips | • Standard |
| Active DMS Fatigue Detection | • Standard |
| In-vehicle vital sign detection | - |
| Road Traffic Sign Recognition | 。Optional |
| Signal light recognition | - |
| night vision system | - |
| passive safety • Standard | 。Optional - none |
| front airbag | • driver's seat |
| • co-pilot | |
| side airbag | • front row |
| side curtain airbags | • Standard |
| front knee airbag | - |
| central airbag | - |
| Seat belt not fastened reminder | • Standard |
| tire pressure monitoring system | • tire pressure display |
| Child seat interface (ISOFIX) | • Standard |
| passive pedestrian protection | - |
| safety tire | - |
| Assist/Control Configuration | |
| • Standard | 。Optional -none |
| parking radar | • forward |
| • rear | |
| Reminder of the vehicle ahead | • Standard |
| • Reverse image | |
| Driving Assistance Vide。 | • 360° panoramic image |
| • transparent image | |
| • cruise control icon | |
| cruise system | 。adaptive cruise |
| Full speed adaptive o cruise | |
| Automatic Lane Change Assist | 。Optional |
| Ramp automatic exit (entry) | 。Optional |
| Assisted driving level | • Level LO |
| 。L2 level | |
| automatic parking | 。Optional |
| Tracking and reversing | - |
| memory parking | - |
| Automatic parking (AUTOHOLD) | • Standard |
| Hill Assist (HAC) | • Standard |
| Hill descent (HDC) | • Standard icon |
| Variable Suspension Adjustment | • Soft and hard |
| air suspension | - |
| Electromagnetic induction suspension | - |
| Variable Steering Ratio System | - |
| Front axle limited slip mode | - |
| Rear axle limited slip mode | - |
| Center differential lock function | - |
| Low-speed four-wheel drive | - |
| Integral Active Steering | - |
| • sports | |
| driving mode selection | • ECO |
| • personalise | |
| • standard comfort | |
| Brake Energy Recovery System | • Standard |
| Low-speed driving warning sound | • Standard |
| external configuration • | Standard 。Optional - none |
| sl^dlghttype | Openable panoramic • sunroof |
| light-sensitive canopy | - |
| roof rack | • Standard |
| sporty appearance kit | - |
| electric spoiler | - |
| Active closed air intake grille | • Standard |
| Aluminum alloy wheels | • Standard |
| side pedal | - |
| Frameless design doors | - |
| hidden door handle | • Standard |
| tow hook | - |
| internal configuration | |
| steering wheel material | • Genuine Leather |
| steering wheel adjustment | up and down + front • and back |
| Electric steering wheel adjustment | • Standard |
| steering wheel function | • multifunction control |
| 。heating | |
| trip computer screen | • color |
| LCD instrument style | • Full LCD |
| LCD Meter Dimensions (inches) | • 9.8 |
| LCD instrument resolution | 1800x606 |
| LCD instrument screen pixel density (PPI) | -194 |
| Comfort/Anti-Theft Configuration | |
| Electric suction door | - |
| electric tailgate | Standard icon |
| Inductive tailgate | Standard icon |
| Electric tailgate position memory | Standard |
| Central locking in the car | Standard |
| smart remote key | |
| Key fob type | mobile phone bluetooth key |
| NFC/RFID key | |
| keyless entry | whole car icon |
| keyless start | Standard icon |
| remote start | Standard |
| remote control vehicle | - |
| vehicle call function | 。Optional |
| Head-Up Display (HUD) | 。Optional |
| Augmented Reality Head-Up Display (AR-HUD) | 。Optional |
| Built-in driving recorder | • Standard |
| Original ETC | • Standard |
| Active Noise Cancellation | - |
| mobile phone wireless charging | • Standard icon |
| Mobile phone wireless charging maximum power (W) | 10 |
| 110V/220V/230V power socket | - |
| Lug gage compartment 12V power interface | • Standard |
| seat configuration • Standard 。Optional - none | |
| seat material | • imitation leather |
| 。Genuine Leather | |
| seat leather style | 。Nappa leather |
| sporty seat | - |
| seat layout | • 2+3 |
| Second row individual seats | - |
| third row seats | - |
| Electric Seat Adjustment | • driver's seat |
| • co-pilot | |
| • move back and forth | |
| Overall adjustment of the driver's seat | • backrest angle |
| • height adjustment | |
| Partial adjustment of the | • headrest |
| driver's seat | • waist |
| • move back and forth | |
| Overall adjustment of passenger seat | • height adjustment • backrest angle |
| • headrest | |
| Partial adjustment of passenger seat | • waist |
| 。leg rest | |
| Overall adjustment of the second row of seats | - |
| Second row seat partial adjustment | - |
| • heating | |
| front seat function | 。ventilation |
| • memory | |
| 。massage | |
| Second row seat functions | 。heating |
| Third row seat function | - |
| boss key | - |
| front/rear armrest | • front row |
| • back row | |
| rear cup holder | • Standard |
| Heated/cooled cup holder | - |
| Rear seat down ratio | • 40:60 |
| Rear seat electric down | - |
| Second row of small table boards Smart Internet • Standarc | i 。Optional - none |
| Central control screen size (inches) | • 11.3 |
| Center console color screen resolution | 1600x1400 |
| Center console color screen pixel density (PPI) | • 188 |
| Touch screen vibration feedback | - |
| screen layout | Traditional dual-screen . layout |
| GPS navigation system | • Standard |
| AR real-world navigation | - |
| Navigation traffic information display | • Standard |
| roadside assistance service | • Standard icon |
| Bluetooth/Car Phone | • Standard |
| Mobile Internet Mapping | - |
| Internet of Vehicles | • Standard |
| 4G/5G network | • 5G |
| OTA upgrade | • Standard |
| OTA version | Alder 1.0.5 |
| face recognition | - |
| Fingerprint recognition | - |
| voiceprint recognition | • Standard |
| emotion recognition | - |
| Voice recognition control system | • Standard |
| Voice free wake-up function | • Standard |
| • main driver | |
| Voice sub-area wake-up recognition function | • co-pilot |
| • second row | |
| Continuous Speech Recognition | • Standard |
| see can say | - |
| voice assistant wake word | Hi, NOMI |
| gesture control | - |
| Wi-Fi hotspot | • Standard |
| Media entertainment • Standard 。Optional - none | |
| Multi-finger flying screen control | - |
| app Store | • Standard |
| multimedia interface | • USB/Type-C |
| Number of USB/Type-C | • 2 front row |
| ports | • 2 back row |
| USB/7ype-C maximum charging power | - |
| Car TV | - |
| rear LCD screen | - |
| simulated sound waves | - |
| audio brand | - |
| Number of speakers | • 7 |
| (units) | 。12 |
| rear multimedia controls | - |
| lighting configuration • Standard 。Optional - none | |
| Low beam lights | • led |
| High beam | • led |
| daytime running lights | • Standard |
| Adaptive far and near light | 。Optional |
| automatic headlights | • Standard |
| turn signal lamp | • Standard |
| Front fog lights | • Standard |
| Penetrating headlights | - |
| through tail lights | - |
| Headlight Adaptive Steering (AFS) | - |
| headlight height adjustment | • Standard |
| headlight cleaning function | - |
| interior ambient light | • 10 colors |
| Active Ambient Mood Lighting | - |
| Lighting Features | - |
| Delayed headlight off | • Standard |
| Headlight rain and fog mode | - |
| glass/mirror • Standard | 。Optional - none |
| electric windows | front row |
| back row | |
| One-button window lift | whole car |
| Window anti-pinch function | Standard |
| electric icon adjustment | |
| heating | |
| electric folding | |
| Exterior mirror function | memory |
| Automatic downturn when reversing | |
| Automatic folding when • locking the car | |
| 。Automatic anti-glare | |
| Interior rearview mirror function | • Automatic anti-glare |
| vanity mirror | Main driving position + lighting Passenger seat + , lighting |
| rear privacy glass | • Standard |
| interior sunshade | - |
| Rain Sensing Wipers | • Standard |
| rear wiper | • Standard |
| rear window open | - |
| Multi-layer soundproof glass | • front row |
| Front windshield electric | |
| heating | |
| heated water nozzle | - |
| air conditioner/refrigerator | • Standard 。Optional |
| Air Conditioning Control | • automatic |
| Mode | |
| Rear independent air conditioner | - |
| rear air outlet | • Standard |
| Temperature zone control | Dual Zone Air • Conditioning |
| Car air purifier | • Standard |
| In-car PM2.5 filter | • Standard |
| HEPA filter | • Standard |
| negative ion generator | • Standard |
| car fragrance device | 。Optional |
| car refrigerator | - |
| Intelligent configuration | |
| Assisted driving operating system | • NIO Pilot |
| Assisted driving chip | • Mobileye EyeQ4 |
| Assisted Driving Chip Computing Power (TOPS) | • 5 |
| Vehicle Intelligent System | • Alder Alder |
| Vehicle Smart Chip | Qualcomm Snapdragon * 8155 |
| In-vehicle system memory (GB) | • 16 |
| In-vehicle system storage (GB) | • 192 . digital key • vehicle monitoring • remote control |
| Mobile App remote control | • charge management • service appointment Smart car search assistant |
| heat pump management system | • Standard |
| Number of cameras outside the car (units) | • 8 |
| Number of cameras in the car (units) | • 1 |
| Ultrasonic radar quantity (unit) | • 12 |
| Number of millimeter wave radars (units) | • 5 |
| Sub-meter high-precision positioning system | - |
| HD map | - |
| Sentry (clairvoyance) mode | • Standard |
| V2X communication | — |
| optional package • Standard 。Optional - none | |
| Customized options | 7 optional packages for appearance, interior, wheels and brakes |
| NIO Pilot Full Package | NIO Pilot Featured Package, Automatic Assisted Navigation Driving (NOP), Highway Automatic Assisted Driving (Highway Pilot), Congestion Automatic Assisted Driving (Traffic Jam Pilot), Turn Signal Control Lane Change (ALC), Driver Drowsiness Warning (DDW), Automatic vehicle call (NS), road sign recognition (TSR), automatic speed limit adjustment (ISA), front side traffic warning (CTA-F) |
| NIO Pilot Select Pack | 。Optional 39000 yuan Adaptive Cruise Control (ACC), Vision Fusion Automatic Parking System (S-APA with Fusion), Automatic Road Keeping (LKA)f Rear Traffic Alert (CTA-R), Traffic Alert-Active Braking (CTA- B), |
| dynamic instrument interface and automatic lane simulation (ALS), automatic control of high and low beams (AHB) | |
| 。Optional 15000 yuan | |
| Nappa Premium Interior Package | Front seat massage, premium Nappa perforated leather seats, premium Nappa leather interior wrapping, Microfiber microfiber velvet headliner |
| 。Optional 25000 yuan | |
| Personalized Signature Design Kit | Custom Signature Pad, Custom Badge |
| 。Optional 4500 yuan | |
| Enhanced Display Kit | Enhanced head-up display system, automatic anti-glare exterior mirrors |
| 。Optional 6500 yuan | |
| Queen's co-pilot | Queen's co-pilot - with electric leg rests and foot rests, parent-child mode seat layout, super long slide rails for co-pilot seat |
| 。Optional 8500 yuan | |
| Airglow orange calipers | Airglow orange calipers |
| 。Optional 3500 yuan | |
| Comfort set | Steering wheel heating, rear seat heating, front seat ventilation, intelligent aroma system, door sill welcome light |
| 。Optional 7500 yuan | |
| Advanced Surround Sound System | 12-speaker surround |
| sound system, 6 | |
| personalized sound | |
| atmosphere modes | |
